T22T/V、T31T/V科爾摩根混合步進電機（推薦使用P7000驅動器）
AKM23C、AKM23D科爾摩根AKM無刷伺服電機
NEMA 23定制電機底座
特點
類型380鋁壓鑄件，環氧樹脂層軸承殼
類型304不銹鋼，.25硬度，拋光推力管
滾珠軸承支架
6063 T-6鋁制、硬涂層陽極氧化和聚四氟乙烯浸漬缸外殼
聚氨酯壓力密封
梯形碳鋼或滾珠絲杠
N2系列選件
標準或定制長度至.1 inch
螺紋，孔，球形，U形夾連桿端
磁定位傳感器
防水選件
線性電位計輸出
同步皮帶，螺旋齒輪，串聯直接傳動
法蘭，U形夾，耳軸電動缸安裝類型
電機或絲杠制動器
環境保護罩
冰點以下或高溫準備
|
MECHANICAL SPECIFICATIONS |
Lead Screw Version |
Ball Screw Version |
|
Max. Stroke Length, in (mm) |
22.5 (571.5) |
22.5 (571.5) |
|
Screw Lead, in |
0.2, 0.5 |
0.2, 0.5 |
|
Screw Diameter, in |
0.625 |
0.625 |
|
Unit Backlash, in (mm) |
0.016 (0.40) |
0.015 (0.38) |
|
Dimensional Standard |
English NFPA Std. |
English NFPA Std. |
|
Motor Mount |
Parallel or Inline |
Parallel or Inline |
|
PERFORMANCE SPECIFICATIONS |
Travel life standard: 25.4 km (1,000,000 in) |
|
|
Max. Thrust Force, lbf (N) |
600 (2670) |
600 (2670) |
|
Max. Velocity, in/s (m/s) |
12 (0.3) |
30 (0.76) |
|
Max. Rated Duty Cycle |
50 |
100 |
|
Std. Operating Temp Range, °F (°C) |
32 to 140 (0 to 60) |
32 to 140 (0 to 60) |
|
Environment |
Humid, Not Direct Contact |
Humid, Not Direct Contact |
